Details
DESCENDED FROM GREATNESS
Take one look at the all-new P-Series, and you’ll notice a striking resemblance to our flagship TT bike, the P5. P-Series benefits from all the racing, wind tunnel time, and testing required to make the P5 the fastest TT bike in the World Tour, but adds a couple features that make it a perfect companion for a triathlon of any distance.
P-Series uses a fork with a D-shaped steerer tube and round stem interface. This means you can use whichever basebar and extensions you prefer, and make changes if your fit or preference changes. It’s also significantly more adaptable if you have very specific fit requirements.
Increased wheel and tire clearance, reduced aerodynamic drag, neater cable routing, and Cervelo’s first internal frame storage all add up to create the bike of choice for those looking to make the most of the time between T1 and T2.
The new P-Series frame is 5.9 grams faster than the outgoing one, but the added tire clearance makes room for the Reserve 52/63 wheels, and 29mm Vittoria tires, which combine for a 30 grams or 3.5 watts savings vs the Reserve 50/Vittoria 28 combo.
New this year on the P-Series, the in-frame storage is designed for a tube, small multi-tool, and a CO2 canister. The hatch is easily removable with or without a bottle in place—just flip the lock and pull.
In addition to the all-new in-frame storage, we still ship every P-Series with the Smartpak 400, our top tube-mounted bento box, which makes fueling on the bike much simpler without sacrificing aerodynamics.
The P-Series is all about adapting to the athlete. Maximum stack increased to 53mm, and we include spacers to bring the basebar up that high. Fitting and positions are evolving, and P-Series offers the most flexibility in an incredibly fast package.
48 | 51 | 54 | 56 | 58 | 61 | |
---|---|---|---|---|---|---|
STACK | 485MM | 506MM | 522MM | 540MM | 559MM | 587MM |
REACH | 381MM | 398MM | 412MM | 425MM | 437MM | 443MM |
EFFECTIVE TOP TUBE @75&DEG SEAT TUBE |
511MM | 533MM | 551MM | 570MM | 587MM | 600MM |
EFFECTIVE TOP TUBE @79&DEG SEAT TUBE |
475MM | 496MM | 513MM | 530MM | 546MM | 567MM |
WHEEL SIZE | 700C | 700C | 700C | 700C | 700C | 700C |
HEAD TUBE ANGLE | 71° | 72.5° | 72.5° | 72.5° | 72.5° | 72.5° |
TRAIL * | 62.4MM | 62.4MM | 62.4MM | 62.4MM | 62.4MM | 62.4MM |
FORK OFFSET | 52MM | 43MM | 43MM | 43MM | 43MM | 43MM |
HEAD TUBE LENGTH | 87.5MM | 101MM | 118MM | 137MM | 157MM | 187MM |
BOTTOM BRACKET DROP | 75MM | 75MM | 75MM | 75MM | 75MM | 75MM |
FRONT CENTER | 582MM | 583MM | 602MM | 622MM | 640MM | 654MM |
WHEELBASE | 975MM | 976MM | 995MM | 1015MM | 1033MM | 1047MM |
STANDOVER HEIGHT | 732MM | 758MM | 773MM | 790MM | 808MM | 836MM |
CHAINSTAY LENGTH | 405MM | 405MM | 405MM | 405MM | 405MM | 405MM |
Specs
Frame | Cervélo All-Carbon, Tapered P Fork |
---|---|
Wheels | Reserve 50mm DT370, 24h (F), 24h (R), 21mm IW, Center-Lock, Tubeless Ready |
Axles | Cervelo Indexed Thru-Axles w/ Lever, Cervelo Aero Thru-Axles, 12x100/142 |
Tires | Vittoria Zaffiro Pro V Folding G2.0 25c |
Bottom Bracket | JY-BB 24 |
Crankset | Shimano Ultegra 8100 52/36 |
Shifters | Shimano Dura Ace Di2 9150 12 spd |
Front Derailleur | Shimano Ultegra Di2 8150, 12 spd |
Rear Derailleur | Shimano Ultegra Di2 8150, 12 spd |
Cassette/Freewheel | Shimano Ultegra CS-R8100, 12 spd, 11-30 |
Chain | Shimano CN-M8100, 12 spd |
Brakes | Riderever RS02, 160mm |
Handlebars | Zipp Vuka Bull Carbon/Zipp Carbon Extensions |
Stem | Cervélo Alloy |
Headset | FSA IS2 1-1/8 x 1-3/8” |
Seatpost | Cervélo SP23 Carbon Tri Post |
Saddle | Prologo Dimension Tri T4.0 |
Pedals | Sold separately |
Accessories & Extras | Smartpak 400, Aerobottle 500, Rear Hydration Mount |
* Subject to change without notice.
Part Numbers
Option | UPC | MPN | Store SKU |
---|---|---|---|
Purple Sunset / 56cm | 042677611479 | 0H1PSEUI2C56 | 210000000596 |
